HQ-005(0)-MC

Model:HQ-005(0)-MC

Item No:HQ-005(0)-MC

Location:Male Inserts

Introduction:HQ Series | HQ-005/0-MC

Product Certification:UL | CE | RoHS | CQC

Suitable Shell

Product Details

HQ Series | Compact Inserts HQ-005/0-MC
Number of  Contacts 5+PE
Rated Current 10A
Rated Voltage 400V
Rated Impulse Voltage 6KV
Pollution degree  3
Insulation Resistance 1010Ω
Pollution degree 2 also 10A 400/690V 6kV 2
Material Polycarbonate
Flammability acc.to UL94 V0
Limiting Temperatures -40~+125
Mechanical Working Life-mating Cycles 500
Contacts HQ-005/0-MC
Material Copper Alloy
Surface Hard Gold Plated | Hard Silver Plated
Contact Resistance ≤3mΩ
Terminal Crimp Terminal
Wire Gauge 0.14~2.5mm2 (AWG 26-14)
Hoods/Housings H3A
Cripmp Contacts 16A
